Sale
ISO-K LF Hoses
ISO-K LF Hoses

ISO-K Large Flange (LF) Metal Flex Hoses

Starting at: $255.30 Starting at: $242.54

ISO-K Large Flange (LF) Metal Flex Hoses are made from SS304L and are used for many applications including roughing and forelines. Standard lengths are 250mm (10″), 500mm (20″), and 1000mm (40″). They are rated to 200 Celsius and 1E-8 Torr. They utilize KF clamps and an elastomeric seal.

Do you need a custom length flex hose? Click Here for our Custom Hose and Bellows Builder!

SKU: SVC-SKU-1578 Category: Tags: , , , , , , , , , , ,
Original price was: $476.10.Current price is: $452.30.
SKU: MH-ISOK-80-500L
Original price was: $365.70.Current price is: $347.42.
SKU: MH-ISOK-80-250L
Original price was: $565.80.Current price is: $537.51.
SKU: MH-ISOK-63-1000L
Original price was: $351.90.Current price is: $334.31.
SKU: MH-ISOK-63-500L
Original price was: $255.30.Current price is: $242.54.
SKU: MH-ISOK-63-250L
Original price was: $779.70.Current price is: $740.72.
SKU: MH-ISOK-80-1000L
Original price was: $434.70.Current price is: $412.97.
SKU: MH-ISOK-100-250L
Original price was: $579.60.Current price is: $550.62.
SKU: MH-ISOK-100-500L
Original price was: $890.10.Current price is: $845.60.
SKU: MH-ISOK-100-1000L
Original price was: $627.90.Current price is: $596.51.
SKU: MH-ISOK-160-250L
Original price was: $1,331.70.Current price is: $1,265.12.
SKU: MH-ISOK-160-500L
Original price was: $2,180.40.Current price is: $2,071.38.
SKU: MH-ISOK-160-1000L

Need a Quote?

Add the items you’re interested in to your cart and choose “Get Quote” at checkout. It’s fast, easy, and there’s no obligation.

Description

ISO-K Large Flange (LF) Metal Flex Hoses are made from SS304L and are used for many applications including roughing and forelines. Standard lengths are 250mm (10″), 500mm (20″), and 1000mm (40″). They are rated to 200 Celsius and 1E-8 Torr. They utilize KF clamps and an elastomeric seal.

Do you need a custom length flex hose? Click Here for our Custom Hose and Bellows Builder!

Additional information

Weight N/A
Iso K Hose Sizes

, , , , , , , , , , ,

ISO-K LF Hoses Dimensions
ISO-K LF Hoses Dimensions



Catalog Part # Size Bellow Wall Thickness Free Length
in A
[mm] in
[mm]
MH-ISOK-63-250L ISO63-250L 0.008 9.84
[0.20] [250]
MH-ISOK-63-500L ISO63-500L 0.008 19.69
[0.20] [500]
MH-ISOK-63-1000L ISO63-1000L 0.008 39.37
[0.20] [1000]
MH-ISOK-80-250L ISO80-250L 0.008 9.84
[0.20] [250]
MH-ISOK-80-500L ISO80-500L 0.008 19.69
[0.20] [500]
MH-ISOK-80-1000L ISO80-1000L 0.008 39.37
[0.20] [1000]
MH-ISOK-100-250L ISO100-250L 0.008 9.84
[0.20] [250]
MH-ISOK-100-500L ISO100-500L 0.008 19.69
[0.20] [500]
MH-ISOK-100-1000L ISO100-1000L 0.008 39.37
[0.20] [1000]
MH-ISOK-160-250L ISO160-250L 0.008 9.84
[0.20] [250]
MH-ISOK-160-500L ISO160-500L 0.008 19.69
[0.20] [500]
MH-ISOK-160-1000L ISO160-1000L 0.008 39.37
[0.20] [1000]
